Screen | 10.4" LCD, resolution: 800×600 |
Principle | Electrical resistance for counting, cyanide free method for hemoglobin |
Parameters | 3-part differential of WBC; 20 parameters (WBC, LYM#, MID#, GRAN#, LYM%, MID%, GRAN%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR) + 3 color histograms (WBC/RBC/PLT) |
Efficient | ≥60 samples/hour |
Storage | 50,000 sample results inclusive of the histograms |
QC Mode | L-J QC mode |
Sample Consumption | Venous mode: 9.6μL, Capillary mode: 9.6μL, Pre-diluted mode: 20μL |
Working mode | Double passages counting detection+independent HGB measurement system; 24 hours with auto standby |
Printer | Built-in thermal recorder, optional external printer, eight report formats |
Interface | 4×USB, 1×ethernet, 1×VGA (for external monitor) |
Reference Value | Baby, Kid, Woman, Man, Normal and Customization |
Cross Contamination Ratio | WBC/RBC/HGB﹤0.5%, PLT﹤1% |
Performance | Parameter Repeatability (CV%)Linear Range WBC≤2.5%0.00-99.9×10^9/L RBC≤2.0%0.00-99.9×10^12/L HGB≤1.5%0-300g/L MCV≤0.4%40-150fL PLT≤5.0%0-999×10^9/L |
